Frezite - Router cutter for portable routers / Mèches pour défonceuses portatives - page 15

6
6.15 www.frezite.com
A142
D R L2 L1 S Z Ref.
15,9 1,6 7,9 47,0 6 2 A142.915.108.06
1,6 7,9 50,0 8 2 A142.915.108.08
19,1 3,2 9,5 50,0 6 2 A142.919.109.06
3,2 9,5 53,0 8 2 A142.919.109.08
22,2 4,8 12,7 52,0 6 2 A142.922.112.06
4,8 12,7 55,5 8 2 A142.922.112.08
25,4 6,3 12,7 51,5 6 2 A142.925.112.06
6,3 12,7 55,0 8 2 A142.925.112.08
28,6 7,9 13,5 53,0 6 2 A142.928.112.06
7,9 13,5 56,0 8 2 A142.928.112.08
31,8 9,5 16,0 55,5 6 2 A142.931.116.06
9,5 16,0 59,0 8 2 A142.931.116.08
38,1 12,7 19,0 58,0 6 2 A142.938.119.06
12,7 19,0 61,0 8 2 A142.938.119.08
MAN HW
Dim. Ref.
9,5x3,1x4,7 701.052
1/8W 705.501
3/32” 706.161
A143
D R L2 L1 S Z Ref.
15,9 1,6 7,9 47,0 6 2 A143.915.108.06
1,6 7,9 50,0 8 2 A143.915.108.08
19,1 3,2 9,5 50,0 6 2 A143.919.109.06
3,2 9,5 53,0 8 2 A143.919.109.08
22,2 4,8 12,7 52,0 6 2 A143.922.112.06
4,8 12,7 55,5 8 2 A143.922.112.08
25,4 6,3 12,7 51,5 6 2 A143.925.112.06
6,3 12,7 55,0 8 2 A143.925.112.08
28,6 7,9 13,5 53,0 6 2 A143.928.112.06
7,9 13,5 56,0 8 2 A143.928.112.08
31,8 9,5 16,0 55,5 6 2 A143.931.116.06
9,5 16,0 59,0 8 2 A143.931.116.08
38,1 12,7 19,0 58,0 6 2 A143.938.119.06
12,7 19,0 61,0 8 2 A143.938.119.08
MAN HW
Dim. Ref.
12,7x5x4,7 701.053
1/8W 705.501
3/32” 706.161
Rounding over cutter
Mèche quart de rond
Beading cutter
Mèche quart de rond
Spare parts - Pièces de rechange
Ball bearing - Roulement
Screw - Vis
Wrench - Clé
Spare parts - Pièces de rechange
Ball bearing - Roulement
Screw - Vis
Wrench - Clé
